Overview M5 Turret Vertical Milling Machine Economic Series Standard configuration: Collet chuck kits Drill chuck Draw b
Description
- Overview
- Product Description
- Detailed Photos
Basic Info.
| Model NO. | M5 |
| Structure | Ram |
| Milling Cutter Type | Vertical Milling Cutter |
| Milling Cutter Structure | Integral |
| Controlling Mode | Artificial |
| Automatic Grade | Manual |
| Precision | Precision |
| Certification | GS, CE, RoHS, ISO 9001 |
| Condition | New |
| process material | metal, plastic etc. |
| Milling head | customied |
| Tilt angle for milling head | customied |
| Dimension(L*W*H) | customied |
| Transport Package | Pallet |
| Specification | 1750*1500*2100 |
| Trademark | Hercules |
| Origin | China |
| HS Code | 8459699000 |
| Production Capacity | 20000sets/Year |
Product Description
M5 Turret Vertical Milling MachineEconomic Series
Standard configuration:
Collet chuck kits
Drill chuck
Draw bar
Reduction sleeve
Work lamp
Electrical cabinet
Coolant system
Wrenches
Plastic Cover
Z axis elevating motor
Optional parts:
3-axis DRO
X-axis ALSGS power feed
Y-axis ALSGS power feed
Z-axis ALSGS power feed
X,Y,Z Mechanical power feed
Air draw bar
Variable speed milling head
6" Machine vice
Separately operate panel box
Machine images and processing steps for reference only:
Product Description
| Model | M5(M5E) |
| Economic Series | |
| Table size(L*W)(mm) | 1370x305 |
| Max.load of table (kg) | 300 |
| X axis(mm) | 1000 900 with power feed |
| Y axis(mm) | 440 |
| Z axis (mm) | 480 |
| Work table T slot (No.-size*pitch) (mm) | 3-15.88x63 |
| Distance between spindle and table(mm) | 20-500 |
| Ram travel (mm) | 500 |
| Travel of spindle quill (mm) | 120 |
| Auto crossward feed(mm/rev) | 0.04/0.08/0.15 |
| Spindle speed(rpm) | 70-3600rpm 10steps |
| Spindle hole taper | NT40 |
| Main Motor | 5HP |
| Tilt angle for milling head | left and right±90º |
| Guiding tracks(X.Y.Z) | X axis dovetail, Y/Z square |
| Dimension(L*W*H)(mm) | 1850x1650x2300 |
| Milling head | Square head with side brake |
| Weight (kg) | 1450 |
| Optional milling head : Round step milling head; Square head with side brake milling head; Variable stepless milling head | |
| Hercules Machinery Equipment Ltd. | |
